Test reason:
The e-cigarette smoke tester is mainly used to test the battery life of the e-cigarette or e-cigarette. The principle is to adjust a certain inspiratory volume or inspiratory pressure, the suction nozzle to the sample once a stop, so repeated cycle until the electronic cigarette or electronic cigarette battery is exhausted or drops to a certain voltage after the number of times, so as to determine the service life of the electronic cigarette or electronic cigarette battery, and improve. Quick test whether the finished e-cigarette works normally: insert the sample into the suction nozzle machine under the working mold to automatically start the suction, and then observe whether the e-cigarette can work normally, such as whether the indicator light is on, whether the battery rod works, whether smoke will come out, etc.
Product parameter table:
| Suction range: | 0-5000pa adjustable (or) | Inspiratory mode: | Miniature air pump |
| Test station: | 2 station | Inspiratory time: | Adjustable from 0 to 10s |
| Stop time: | Adjustable from 0 to 10s | Counter: | The value ranges from 0 to 999999 |
| Power supply: | AC220V,1A | Volume: | It's about 400 x 300 x 180 cm |
| Test station: | Simplex (multiple stations can be customized) | ||
| Negative pressure capacity: | 0--5000pa (or), accuracy > Plus or minus 2% | ||
| Pressure sensing: | Imported precision differential pressure type negative pressure sensor | ||
| Suction resistance test method: | Quadrature method | ||
| Suction flow rate: | 0~100ml/s adjustable, standard 17.5ml/s | ||
| Suction mode: | Piston type, each suction capacity can be set accurately | ||
| Pumping capacity per mouth: | 5-250m adjustable, precision > Plus or minus 1 | ||
| Suction time: | Adjustable for 2 to 10 seconds (or) | Stop time: | 2-100S Adjustable (or) |
| Counter: | LCD,0-999999 can be set | ||
| Control mode: | PLC+ liquid crystal text + self-programming | ||
| Operation and display: | Color touch screen, all parameters are concentrated in the screen setting, display, automatic control | ||
| Power supply: | AC220V, 5A | Weight: | About 95 kg |
